波长 Wavelength (nm)
|
355
|
|
输出功率 Output Power (W)
|
1000-5000
|
|
工作方式 Working Mode
|
LD pumped, pulse
|
|
Q开关方式 Q-Switch
|
Acousto-Optic
|
|
光斑模式
Beam Mode
|
横模 Transverse
|
TEM00
|
|
纵模 Longitude
|
Multi-longitude
|
|
线宽 Spectral Linewidth (nm)
|
<0.1
|
|
偏振方式 Polarization
|
Line polarization
|
|
脉宽 Pulse width (ns)
|
<25 (typical, @ 20KHz)
|
|
重复频率 Repitition Rate (KHz)
|
20~200
|
|
峰值功率 Peak Power (KW)
|
10 (typical, @5W)
|
|
光束发散角Beam Divergence (full angle, mrad)
|
<1.5
|
|
光束直径Beam Diameter at Aperture (mm, 1/e2)
|
<1.0 (ytpical)
|
|
光束椭圆度 Beam Roundness
|
>90%
|
|
功率稳定性Power Stability (RMS, over 4 hours)
|
<5%
|
|
尺寸 Dimensions (L×W×H, mm)
|
330X160X115
|
|
制冷方式Cooling System
|
TEC+水冷
|
|
预热时间Warm-up Time (minutes)
|
<15
|
|
工作温度Operation Temperature (℃)
|
18~30
|
|
使用寿命Expected Lifetime (hours)
|
>10,000
|
|
保修期Warranty Time
|
1 year
|
|
|
