厂商 :广州市白云区富鑫空气过滤设备厂(销售部)
广东 广州市- 主营产品:
- 过滤纸
- 过滤棉
- 过滤器
耐高温高效过滤器
产品特性:
* 一般为有隔板结构,使用超细、无碱、阻燃、耐高温高效玻纤滤纸,
* 铝箔作分隔板,防潮、耐温、防收胀变形;
* 镀锌框、不锈钢框架、进口特制耐高温密封胶密封。
* 阻力低,效率高,耐温性能好,适应于250-350℃环境下长期使用;
*每台高效过滤器经过严格测试。
用途:
主要用于食品、制药等生产环节要求烘干的超洁净烘箱、汽车涂装等要求高温空气净化的设备和系统。
Heat-resistance high efficiency filter
Specialty:
* This series of high temperature efficiency filter usually is of pleated HEPA filter type. Using high temperature resistance fiberglass media
*separated by aluminum foil, anti-Moisture, high temperature resistance, and prevent deformation.
* It is featured by high efficiency and dust holding, low resistance, heat resistance.
* Galvanized frame, stainless steel frame, imported special high temperature resistant sealant.
*The efficiency can reach from F9 to H14, it can work long time under 250℃,the max working temperature is 350℃.
* Each filter is individually tested via PSL particle.
Application:
Designed for the high temperature air purification oven in food factory or pharmaceutical factory etc...
技术参数:Specification
型号Type |
规格Size(mm) (宽x高x深) |
额定风量Rated Airflow(m3/h) |
过滤面积Filter area(m2) |
初阻力Initial resistance (Pa) |
效率Average Arrestance |
|||
H10 |
H12 |
H13 |
H14 |
|||||
FX-HT |
484x484x150 |
530 |
6.0 |
≤150 |
≤190 |
≤220 |
≤240 |
≧99.97% |
610x610x150 |
1000 |
10.2 |
||||||
484x484x220 |
1000 |
9.8 |
||||||
610x610x220 |
1600 |
15.8 |
||||||
305*610*292 |
1000 |
10.1 |
||||||
610*610*292 |
2000 |
20.9 |
注: 特殊规格尺寸和厚度可根据客户要求定做!
