商品详细描述
研华PC/104主板PCM-3343
DM&P Vortex86DX-1 GHz PC/104 SBC, LCD, Ethernet, CFC, Onboard Memory
Main Features
Ultra low power, fanless DM&P Vortex86DX- 1 GHz and 256 MB onboard DDR2 memory
CRT+LCD dual display outputs, 24-bit LVDS/TTL supported
Integrated Floating-point Unit
Supports 2 Fast Ethernet ports in standard PC/104 96 x 90 mm dimensions
Supports Embedded Software APIs and Utilities
Supports embedded OS: Windows CE 5.0, Windows CE 6.0, Windows XP Embedded, DOS, Linux, QNX, VxWorks
订货信息
PCM-3343F-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
PCM-3343L-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
PCM-3343Z2-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
PCM-3343Z-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
欢迎来电咨询研华主板,研华嵌入式主板,研华PC/104主板,研华工业主板等研华工控产品的方案。
DM&P Vortex86DX-1 GHz PC/104 SBC, LCD, Ethernet, CFC, Onboard Memory
Main Features
Ultra low power, fanless DM&P Vortex86DX- 1 GHz and 256 MB onboard DDR2 memory
CRT+LCD dual display outputs, 24-bit LVDS/TTL supported
Integrated Floating-point Unit
Supports 2 Fast Ethernet ports in standard PC/104 96 x 90 mm dimensions
Supports Embedded Software APIs and Utilities
Supports embedded OS: Windows CE 5.0, Windows CE 6.0, Windows XP Embedded, DOS, Linux, QNX, VxWorks
订货信息
PCM-3343F-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
PCM-3343L-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
PCM-3343Z2-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
PCM-3343Z-256A1E DM&P Vortex86DX-1GHz PC/104 SBC, LCD, LAN, CFC, On board memory
欢迎来电咨询研华主板,研华嵌入式主板,研华PC/104主板,研华工业主板等研华工控产品的方案。
