商品详细描述
USB线
USB 数据线
USB打印线
1. USB A TYPE公端接口对接USB B TYPE公端接口
2. USB2.0标准线材,适用于USB设备数据传输
4. 产品长度及颜色可定制
5.特性
Connector: Nickel plated, Gold plated optional
Conductor: pure copper
Edition:USB2.0
Gauge:28AWG,24AWG optional
Length: according to requirement
color: according to requirement
电特性
100% open & short test
Hi-Pot: DC 300V 10ms
Insulation Resistance: PE: DC-500V 100M OHM/KM Min. at 20 degree
SR-PVC: DC-500V 10M OHM/KM Min. at 20 degree
Contact Resistance: 28AWG-237.25 OHM/KM Max. at 20 degree
24AWG-93.25 OHM/KM Max. at 20 degree
Shield up to 65%~85% braid.
Working temperature:-30~80 degree
机械特性
Over mold: PVC 45-60Pa
Pre mold: PE low density
Contact : copper
Insertion Force: 10N Max
Withdraw Force: 7 N Min
USB 数据线
USB打印线
1. USB A TYPE公端接口对接USB B TYPE公端接口
2. USB2.0标准线材,适用于USB设备数据传输
4. 产品长度及颜色可定制
5.特性
Connector: Nickel plated, Gold plated optional
Conductor: pure copper
Edition:USB2.0
Gauge:28AWG,24AWG optional
Length: according to requirement
color: according to requirement
电特性
100% open & short test
Hi-Pot: DC 300V 10ms
Insulation Resistance: PE: DC-500V 100M OHM/KM Min. at 20 degree
SR-PVC: DC-500V 10M OHM/KM Min. at 20 degree
Contact Resistance: 28AWG-237.25 OHM/KM Max. at 20 degree
24AWG-93.25 OHM/KM Max. at 20 degree
Shield up to 65%~85% braid.
Working temperature:-30~80 degree
机械特性
Over mold: PVC 45-60Pa
Pre mold: PE low density
Contact : copper
Insertion Force: 10N Max
Withdraw Force: 7 N Min
