商品详细描述
Vertical
Input Channels 4Ch+EXT
Bandwidth DC~150MHz(-3dB)
Rise Time 2.3ns
Vertical Resolution 8 bits
Vertical Resolution@ 1MΩ 2mV~5V/div
Vertical Resolution@ 50/75Ω 2mV~1V/div
Input Coupling AC, DC, GND
Input Impedance 1MΩ// 16pF
DC Gain Accuracy ±(3% X |reading| + 0.1div+ 1mV)
Polarity Normal and inverted
Maximum Input Impedance @1MΩ 300V (DC+AC peak), CAT I
Maximum Input Impedance @50/75Ω 5 Vrms ,CAT I
OffsetPositionRange 2mV/div ~ 100mV/div: ±0.5V
200mV/div ~ 5V/div: ±25V
Bandwidth Limit 20MHz (-3dB)
Waveform Signal Processing Addition, Subtraction, multiplication, division, FFT, FFTrms
Trigger
Source Dual channel: CH1, CH2, Line, Ext ; 4 channel: CH1, CH2, CH3, CH4, Line, Ext
Trigger Mode Auto (Auto (supports Roll Mode for 100 ms/div and slower), Normal, Single
Trigger Type Edge, Pulse Width, Video, Runt, Rise & Fall, Alternative, Event-Delay (1~65,535) events, Time-Delay(10nS~10S), I2C, SPI, UART
TriggerHold-off Range 10ns~10s
Coupling AC, DC, LF rej, HF rej, Noise rej
Sensitivity DC~50MHz approx. 1div or 1.0mV
50MHz~150MHz approx. 1.5div or 15mV
150MHz~350MHz approx. 2div or 20mV
EXT Trigger
Range ±15V
Sensitivity DC~150MHz pprox.100mV
150MHz~250MHz approx. 150mV
250MHz~350MHz approx. 150mV
Input Impedance 1MΩ±3%, ~16pF
Horizontal
Range 1ns/div~100s/div (1-2-5steps); ROLL: 100ms/div~100s/div
Pre-Trigger 10div maximum
Post-Trigger 1,000div
Accuracy ±20 ppm over any ≧1 ms time interval
Signal Acquisition System
Real Time Sample Rate 5GSa/s
Equivalent Time Sample Rate 100GSa/s maximum for all models
Record Length 25k points
Acquisition Mode Normal, Average, Peak Detect, High resolution, Single
Normal: Acquire sampled values
Average: From 2 to 256 waveforms included in average
Peak Detect: Catches glitches as narrow as 2ns at all sweep speeds
Hi Res: Real-time boxcar averaging reduces random noise and increases vertical resolution
X-Y Mode
X-axis input Channel 1; Channel 3
Y-axis input Channel 2; Channel 4
Phase Shift ±3° at 100kHz
Cursors and Measurement
Cursors Amplitude, Time, Gating available
Automatic Measurement 28 sets: Vpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/Overshoot, Freq, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle, Phase, eight different delay measurements (FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF)
Interface
RS-232C port DB-9port
USB port 2 sets USB 2.0 high-speed host port; 1setUSB 2.0 high speed device port
Ethernet RJ-45 port, 10/100Mbps
VGAVideoPort DB-15port, SVGA monitor output
Line Output 3.5mm stereo output jack for Go/NoGo audio alarm
GPIB(Optional) USB to GPIB converter
Go/NoGo BNC Maximum 5V /10mA TTL open collector ouput
Kensington Style Lock Rear panel security slot connects to standard Kensington style lock
Power Source
LineVoltageRange AC 100V ~ 240V, 48Hz ~ 63Hz, Auto selection
Miscellaneous
Multi-language Menu Available
On-line Help Available
Time clock Time and Data ,Provide the Data/Time for saved data
Dimensions and Weight 400(W) x 200(H) x 130(D), approx. 4 kg.
Input Channels 4Ch+EXT
Bandwidth DC~150MHz(-3dB)
Rise Time 2.3ns
Vertical Resolution 8 bits
Vertical Resolution@ 1MΩ 2mV~5V/div
Vertical Resolution@ 50/75Ω 2mV~1V/div
Input Coupling AC, DC, GND
Input Impedance 1MΩ// 16pF
DC Gain Accuracy ±(3% X |reading| + 0.1div+ 1mV)
Polarity Normal and inverted
Maximum Input Impedance @1MΩ 300V (DC+AC peak), CAT I
Maximum Input Impedance @50/75Ω 5 Vrms ,CAT I
OffsetPositionRange 2mV/div ~ 100mV/div: ±0.5V
200mV/div ~ 5V/div: ±25V
Bandwidth Limit 20MHz (-3dB)
Waveform Signal Processing Addition, Subtraction, multiplication, division, FFT, FFTrms
Trigger
Source Dual channel: CH1, CH2, Line, Ext ; 4 channel: CH1, CH2, CH3, CH4, Line, Ext
Trigger Mode Auto (Auto (supports Roll Mode for 100 ms/div and slower), Normal, Single
Trigger Type Edge, Pulse Width, Video, Runt, Rise & Fall, Alternative, Event-Delay (1~65,535) events, Time-Delay(10nS~10S), I2C, SPI, UART
TriggerHold-off Range 10ns~10s
Coupling AC, DC, LF rej, HF rej, Noise rej
Sensitivity DC~50MHz approx. 1div or 1.0mV
50MHz~150MHz approx. 1.5div or 15mV
150MHz~350MHz approx. 2div or 20mV
EXT Trigger
Range ±15V
Sensitivity DC~150MHz pprox.100mV
150MHz~250MHz approx. 150mV
250MHz~350MHz approx. 150mV
Input Impedance 1MΩ±3%, ~16pF
Horizontal
Range 1ns/div~100s/div (1-2-5steps); ROLL: 100ms/div~100s/div
Pre-Trigger 10div maximum
Post-Trigger 1,000div
Accuracy ±20 ppm over any ≧1 ms time interval
Signal Acquisition System
Real Time Sample Rate 5GSa/s
Equivalent Time Sample Rate 100GSa/s maximum for all models
Record Length 25k points
Acquisition Mode Normal, Average, Peak Detect, High resolution, Single
Normal: Acquire sampled values
Average: From 2 to 256 waveforms included in average
Peak Detect: Catches glitches as narrow as 2ns at all sweep speeds
Hi Res: Real-time boxcar averaging reduces random noise and increases vertical resolution
X-Y Mode
X-axis input Channel 1; Channel 3
Y-axis input Channel 2; Channel 4
Phase Shift ±3° at 100kHz
Cursors and Measurement
Cursors Amplitude, Time, Gating available
Automatic Measurement 28 sets: Vpp, Vamp, Vavg, Vrms, Vhi, Vlo, Vmax, Vmin, Rise Preshoot/ Overshoot, Fall Preshoot/Overshoot, Freq, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle, Phase, eight different delay measurements (FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF)
Interface
RS-232C port DB-9port
USB port 2 sets USB 2.0 high-speed host port; 1setUSB 2.0 high speed device port
Ethernet RJ-45 port, 10/100Mbps
VGAVideoPort DB-15port, SVGA monitor output
Line Output 3.5mm stereo output jack for Go/NoGo audio alarm
GPIB(Optional) USB to GPIB converter
Go/NoGo BNC Maximum 5V /10mA TTL open collector ouput
Kensington Style Lock Rear panel security slot connects to standard Kensington style lock
Power Source
LineVoltageRange AC 100V ~ 240V, 48Hz ~ 63Hz, Auto selection
Miscellaneous
Multi-language Menu Available
On-line Help Available
Time clock Time and Data ,Provide the Data/Time for saved data
Dimensions and Weight 400(W) x 200(H) x 130(D), approx. 4 kg.
