商品详细描述
| 是否提供加工定制 | 否 | 品牌 | I-TORK |
| 型号 | IQL系列 | 产品用途 | 电动调节阀 |
| 驱动能源 | 电动执行器 |
|
General Specifications |
|
|
Enclosure |
IP66, O-ring Sealed |
|
Power Supply |
110,220VAC/1Ph/50,60Hz,380~440VAC/3Ph/50,60Hz 24VDC |
|
Control Power |
110,220VAC/1Ph/50,60Hz, |
|
Duty Cycle (ON-OFF) |
S2 : Max 30 min(IQL20)/ Max 20 min(IQL25) |
|
Duty Cycle (Modulating) |
S4 : 50%, 1,200 Start/Hour(IQL20)/30%, 800 Start/Hour(IQL25) |
|
Motor |
Induction Motor with Thermal Protector (High 150℃± 5 ℃/ Low 97℃± 15℃) |
|
Limit Switches |
4 xSPDT(2 for Close, 2 for Open),250VAC,16A |
|
Force Switches |
2 xSPDT(1 for Close, 1 for Open),250VAC,16A |
|
Position Indication |
Continuous mechanical indicator with arrow |
|
Manual Override |
Hand-wheel withswitchablede-clutchablelever |
|
Terminal Block |
Screw and Lever Push Type (Spring Loaded) |
|
Cable Entries |
2 -PF3/4",NPT3/4",M25X1.5 |
|
Space Heater |
5W(110/220VAC) for anti-condensation |
|
Ambient Temperature |
Basic Actuator: -20 ~ +70℃ c/wControl Option: -10℃~ +60℃ |
|
Ambient Humidity |
90%RH Max (Non-Condensing) |
