sierra EM9190模块

厂商 :深圳合众创意科技有限公司

广东 深圳市
  • 主营产品:
  • sierra模块
联系电话 :13714189441
商品详细描述

深圳合众创意科技有限公司是sierra模块与高新兴模块的授权代理商,所出售的产品都是全新原装正 品。

我们提供技术支持,保修一年。批量价格从优,可联系客服详谈。

AirPrime? EM9190 5G NR Sub-6 GHz and mmWa ve Module

Drive IoT innovation with next-generation technology

The EM9190 module is part of the EM Series offering global 5G connectivity. Designed in an M.2 form factor, the EM9190 will soon be compatible with Sierra Wireless's EM7690 4G LTE-A Pro module, to help facilitate the migration and differentiation between 4G LTE and 5G.

This 5G NR Sub-6 GHz and mmWa ve embedded module delivers up to 5.5Gbps downlink speed and 330Mbps uplink speed. With automatic 4G and 3G fallback networks, and a built-in GNSS receiver, the EM9190 is applicable to a wide range of M2M and IoT applications such as industrial routers, home gateways, industrial and consumer laptops, rugged tablet PCs, video surveillance and digital signage.



5G NR


Category
5G NR Sub-6 and mmWa ve
Frequency Bands
Sub-6: n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n39, n40, n41, n66, n71, n77, n78, n79, mmWa ve: n257, n258, n260, n261

4G LTE
Category
Cat-20
Frequency Bands
B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B14, B18, B19, B20, B25, B26, B28, B29, B30, B32, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71

LOCATION SERVICES
Satellite Systems
Galileo, Glonass, GPS, Beidou (Bands: L1 and L5) EMBEDDED SOFTWARE

System Drivers
Windows? 10, Linux, Android RIL INTERFACES

USB
USB 3.1 (Linux)
PCIe
PCIe generation 3 (or 2), 1 lane

HARDWARE
Dimensions
30x52x2.38mm

APPROVALS
Planned Carrier
AT&T (FirstNet), docomo, LGU+, Telstra, Verizon
Regulatory
FCC, GCF, KC, PTCRB, EU RED, JATE/Telec
