LFL3-CK-U-PVC5浮球

电气特性

触点负载

230 V AC/3 A/200 VA; 150 V DC/3 A/100 W resistive load

额定绝缘电压

300 V

脉冲耐受电压

4 kV

指令符合

Low voltage

Directive 2014/35/EU

EN 60947-5-1:2004 + Cor.:2005 + A1:2009

Conformity

防护等级

IEC 60529:2001

Application

描述

mercury (Hg) change-over contact

Function and system design

Equipment architecture

This device may be used with any sequential circuit, as long as the circuit can support the electrical circuit values of the switching elements.

操作条件

安装条件

Installation instructions

range of application and minimum length between mounting and float:
- PVC version: ≥ 50 mm (2 inch), preferred for water
- PUR version: ≥ 100 mm (4 inch), preferred for fuels, heating oils, oily fluids
- CSM/CM version: ≥ 100 mm (4 inch), preferred for many acids and lyes
- TPK version: ≥ 100 mm (4 inch), preferred for many acids and lyes
mounting:
- The float switch is mounted either from sidewards through a cable gland ≥ G1A into the vessel or
- by means of a counter weight or rods (e. g. float switch combination) from the top.
The pivot of the cable should always be horizontal.

Process conditions

过程压力(静压)

sleeve design: ≤ 3 bar at 20 °C (68 °F)
ball design: ≤ 2 bar at 20 °C (68 °F)

Density

sleeve design: ≥ 0.8 g/cm³
ball design: ≥ 0.6 g/cm³

周围环境

环境温度

PVC version: 5 ... 70 °C (41 ... 158 °F)
PUR version: 5 ... 70 °C (41 ... 158 °F)
CSM/CM version: -20 ... 70 °C (-4 ... 158 °F)
TPK version: 5 ... 70 °C (41 ... 158 °F)

储存温度

-25 ... 70 °C (-13 ... 158 °F)

海拔

≤ 2000 m above MSL

机械特性

防护等级

IP68

Mechanical construction

材料

float: PP (Polypropylene)
cable:
- PVC version: PVC cable, highly flexible (3 x 0.75 mm²)
- PUR version: PUR cable, highly flexible (3 x 0.50 mm²)
- CSM/CM version: CSM/CM cable (chlorinated polyethylene, (3 x 0.75 mm²))
- TPK version: TPK cable, (3 x 0.75 mm²)
