型号
Model
|
效率规格
Class
|
外形尺寸
Dimensions
W×H×D mm
|
袋数
Pocket Number
|
有效过滤面积
Net Media m2
|
初阻力/风量
Resistance/ASirflow
Pa/m3/h
|
|
HD/SE 6660/08-F5
|
F5
|
592×592×600
|
8
|
6.18
|
20/2500
|
40/3600
|
70/5000
|
|
HD/SE 6660/06-F5
|
F5
|
592×592×600
|
6
|
4.64
|
20/2500
|
40/3600
|
70/5000
|
|
HD/SE 6650/06-F5
|
F5
|
592×592×500
|
6
|
3.86
|
25/2500
|
40/3600
|
70/5000
|
|
HD/SE 3660/04-F5
|
F5
|
287×592×600
|
4
|
3.09
|
20/1250
|
40/1800
|
70/2500
|
|
HD/SE 3660/03-F5
|
F5
|
287×592×600
|
3
|
2.32
|
20/1250
|
40/1800
|
70/2500
|
|
HD/SE 3650/03-F5
|
F5
|
287×592×500
|
3
|
1.93
|
25/1250
|
40/1800
|
70/2500
|
|
HD/SE 5660/06-F5
|
F5
|
490×592×600
|
6
|
4.64
|
20/2500
|
40/3000
|
70/4000
|
|
HD/SE 5660/05-F5
|
F5
|
490×592×600
|
5
|
3.87
|
20/2500
|
40/3000
|
70/4000
|
|
HD/SE 5650/05-F5
|
F5
|
490×592×500
|
5
|
3.22
|
20/2500
|
40/3000
|
70/4000
|
|
HD/SE 6665/10-F6
|
F6
|
592×592×650
|
10
|
8.06
|
35/2500
|
60/3600
|
100/5000
|
|
HD/SE 6665/08-F6
|
F6
|
592×592×650
|
8
|
6.60
|
35/2500
|
65/3600
|
110/5000
|
|
HD/SE 6655/05-F6
|
F6
|
592×592×550
|
8
|
5.58
|
40/2500
|
75/3600
|
125/5000
|
|
HD/SE 3665/05-F6
|
F6
|
287×592×650
|
5
|
4.03
|
35/1250
|
60/1800
|
100/2500
|
|
HD/SE 3665/04-F6
|
F6
|
287×592×650
|
4
|
3.30
|
35/1250
|
65/1800
|
110/2500
|
|
HD/SE 3655/04-F6
|
F6
|
287×592×550
|
4
|
2.79
|
40/1250
|
75/1800
|
125/2500
|
|
HD/SE 5665/08-F6
|
F6
|
490×592×650
|
8
|
6.45
|
35/2000
|
60/3000
|
100/4000
|
|
HD/SE 5665/06-F6
|
F6
|
490×592×650
|
6
|
4.95
|
35/2000
|
65/3000
|
110/4000
|
|
HD/SE 5655/06-F6
|
F6
|
490×592×550
|
6
|
4.19
|
40/2000
|
75/3000
|
125/4000
|
|
HD/SE 6665/10-F7
|
F7
|
592×592×650
|
10
|
8.06
|
45/2500
|
70/3600
|
120/5000
|
|
HD/SE 6665/08-F7
|
F7
|
592×592×650
|
8
|
6.60
|
45/2500
|
75/3600
|
125/5000
|
|
HD/SE 6655/08-F7
|
F7
|
592×592×550
|
8
|
5.58
|
50/2500
|
80/3600
|
125/5000
|
|
HD/SE 3665/05-F7
|
F7
|
287×592×650
|
5
|
4.03
|
45/1250
|
70/1800
|
120/2500
|
|
HD/SE 3665/04-F7
|
F7
|
287×592×650
|
4
|
3.30
|
45/1250
|
75/1800
|
120/2500
|
|
HD/SE 3655/04-F7
|
F7
|
287×592×550
|
4
|
2.79
|
50/1250
|
80/1800
|
125/2500
|
|
HD/SE 5665/08-F7
|
F7
|
490×592×650
|
8
|
6.45
|
45/2000
|
70/3000
|
120/4000
|
|
HD/SE 5665/06-F7
|
F7
|
490×592×650
|
6
|
4.95
|
45/2000
|
75/3000
|
120/4000
|
|
HD/SE 5655/06-F7
|
F7
|
490×592×550
|
6
|
4.19
|
50/2000
|
80/3000
|
125/4000
|
|
HD/SE 6665/12-F8
|
F8
|
592×592×650
|
12
|
9.44
|
60/2500
|
100/3600
|
170/5000
|
|
HD/SE 6665/10-F8
|
F8
|
592×592×650
|
10
|
8.06
|
60/2500
|
100/3600
|
170/5000
|
|
HD/SE 6665/08-F8
|
F8
|
592×592×650
|
8
|
6.60
|
65/2500
|
105/3600
|
175/5000
|
|
HD/SE 6655/08-F8
|
F8
|
592×592×550
|
8
|
5.58
|
70/2500
|
110/3600
|
175/5000
|
|
HD/SE 3665/06-F8
|
F8
|
287×592×650
|
6
|
4.72
|
60/1250
|
100/1800
|
170/2500
|
|
HD/SE 3665/05-F8
|
F8
|
287×592×650
|
5
|
4.03
|
60/1250
|
100/1800
|
170/2500
|
|
HD/SE 3665/04-F8
|
F8
|
287×592×650
|
4
|
3.30
|
65/1250
|
105/1800
|
175/2500
|
|
HD/SE 3655/04-F8
|
F8
|
287×592×550
|
4
|
2.79
|
70/1250
|
110/1800
|
175/2500
|
|
HD/SE 5665/10-F8
|
F8
|
490×592×650
|
10
|
7.87
|
60/2000
|
100/3000
|
170/4000
|
|
HD/SE 3665/08-F8
|
F8
|
490×592×650
|
8
|
6.45
|
60/2000
|
100/3000
|
170/4000
|
|
HD/SE 5665/06-F8
|
F8
|
490×592×650
|
6
|
4.95
|
65/2000
|
105/3000
|
175/4000
|
|
HD/SE 5655/06-F8
|
F8
|
490×592×550
|
6
|
4.19
|
75/2000
|
110/3000
|
175/4000
|
注:
(1)表中仅列出部分常用规格,我公司可按照用户要求,制造其它规格的HD/SE袋子式过滤器.
(2)HD/SE过滤器迎风面的安装框厚度为21mm,若用户需要25mm或其它尺寸,请在订货时说明.
