RX-DD硬度计

RX-DD硬度计美国CHECKLINE原装进口

RX-DD硬度计

深圳市汉斯福特科技有限公司

李经理：13421312443


概述
Available Scales: A, AO, B, C, D, DO, E, M, O, OO, OOO (Asker, ISO, DIN & JIS Scales also available, inquire)
The new Check-Line RX-DD is a precision Digital Durometer ideal for laboratory use. It features a large direct drive LCD display, RS232 data ports for computer compatibility, a locking feature to prevent accidental erasure of tolerances, automatic shutoff, low battery warning, and accessories such as MTI and SPC type printers, audio attachments and software.


Type M Durometers require test stand OS-3 per ASTM D2240.


特性
1. High and low buttons for setting tolerance limits
2. Solid state circuitry with LCD display
3. One year warranty
4. Holds Peak reading until reset
5. 0.1 Unit Resolution
6. Supplied in custom fit carrying case
7. Includes NIST-Traceable Calibration Certificate
8. Conforms to ASTM D-2240
9. Optional Removable Stainless Steel Barrel for Medical and Food Applications
10. Minimum Sample Thickness -Type A = 6 mm (1/4") -Type M = 1.25 mm (0.050")


技术参数
Measruing Range 0 - 100 Units
Resolution 0.1 Units
Dimensions 2.25" x 6.125"
Weight 7.15 oz.
Power Supply (2) 3V CR-2450 Batteries
115V AC Adapter Included. 230V AC Adapter Optional
Warranty 1 year


订货型号
Item Description Price
RX-DD-A RX-DD-A Type A Digital Durometer
RX-DD-AO RX-DD-AO Type AO Digital Durometer, supplied with BF-1 Footer
RX-DD-D RX-DD-D Type D Digital Durometer
RX-DD-B RX-DD-B Type B Digital Durometer
RX-DD-C RX-DD-C Type C Digital Durometer
RX-DD-CF RX-DD-CF Type M Digital Durometer
RX-DD-E RX-DD-E Type E Durometer, supplied with DIN-FA 18mm Footer
RX-DD-DO RX-DD-DO Type DO Digital Durometer
RX-DD-O RX-DD-O Type O Digital Durometer
RX-DD-OO RX-DD-OO Type OO Digital Durometer
RX-DD-OOO RX-DD-OO Type OOO Digital Durometer
RX-DD-M RX-DD-M Type M Digital Durometer
RX-DD-ASK-C-SS Asker C Digital Durometer with Stainless Steel Barrel

Accessories
G11-0012 Spare 110V AC Adapter for RX-DD / DD-100 / MTG
G11-0014 220V AC Adapter for RX-DD / DD-100 / MTG
RSS Upgrade to Removable Stainless Steel Barrel for Medical and Food Applications
DD-DB1 "Smart" USB Data Transfer Cable, Sends data to any Windows program with press of a button
G13-0055 USB Data Transfer Cable from DD-100 or RX-DD Digital Durometers to a PC for transfer to a Wedge or Data Collection program purchased from a 3rd party


The RX-DD is supplied as a complete kit including the durometer, 115V AC adapter & instruction manual in a foam-fitted metal carrying case.
