PC耐热HF1110

厂商 ：沙泊塑料有限公司（中山）

广东 中山
  • 主营产品：
  • TPU
  • PPS
  • POM
联系电话 ：13432026331
商品详细描述
美国沙伯 PC聚碳酸酯
通用耐热级
HF1110 耐热。HF1110R 耐热，高流动，脱模剂。HF1130 抗UV，耐热。HF1130R 高流动，脱模剂，抗UV。HF1140 耐热，FDA食品级。
HF1140R 耐热，FDA食品级，脱模剂。   注: 包装：原厂原包，25公斤/包  规格：符合RoHS认证标准 25公斤/包起订，批量可折扣.珠三角内1-3天到达,国内各地3-7天到货欢迎新老客户来电咨询订购？！！！

LEXAN ? Resin HF1110






LEXAN HF1110 is a high flow grade especially designed for applications that require thin wall sections and high flow lengths.


TYPICAL PROPERTIES (1)
MECHANICAL Value Unit Standard
Taber Abrasion, CS-17, 1 kg 32 mg/1000cy SABIC Method
Tensile Stress, yield, 50 mm/min 63 MPa ISO 527
Tensile Stress, break, 50 mm/min 50 MPa ISO 527
Tensile Strain, yield, 50 mm/min 6 % ISO 527
Tensile Strain, break, 50 mm/min 70 % ISO 527
Tensile Modulus, 1 mm/min 2350 MPa ISO 527
Flexural Stress, yield, 2 mm/min 90 MPa ISO 178
Flexural Modulus, 2 mm/min 2300 MPa ISO 178
Hardness, H358/30 95 MPa ISO 2039-1
IMPACT Value Unit Standard
Izod Impact, unnotched 80*10*3 +23°C NB kJ/m? ISO 180/1U
Izod Impact, unnotched 80*10*3 -30°C NB kJ/m? ISO 180/1U
Izod Impact, notched 80*10*3 +23°C 60 kJ/m? ISO 180/1A
Izod Impact, notched 80*10*3 -30°C 11 kJ/m? ISO 180/1A
Charpy 23°C, V-notch Edgew 80*10*3 sp=62mm 60 kJ/m? ISO 179/1eA
Charpy -30°C, V-notch Edgew 80*10*3 sp=62mm 12 kJ/m? ISO 179/1eA
Charpy 23°C, Unnotch Edgew 80*10*3 sp=62mm NB kJ/m? ISO 179/1eU
Charpy -30°C, Unnotch Edgew 80*10*3 sp=62mm NB kJ/m? ISO 179/1eU
THERMAL Value Unit Standard
Thermal Conductivity 0.2 W/m-°C ISO 8302
CTE, 23°C to 80°C, flow 7.E-05 1/°C ISO 11359-2
Ball Pressure Test, 125°C +/- 2°C PASSES - IEC 60695-10-2
Vicat Softening Temp, Rate B/50 139 °C ISO 306
Vicat Softening Temp, Rate B/120 140 °C ISO 306
HDT/Be, 0.45MPa Edgew 120*10*4 sp=100mm 133 °C ISO 75/Be
HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm 121 °C ISO 75/Ae
PHYSICAL Value Unit Standard
Mold Shrinkage on Tensile Bar, flow (2) (5) 0.5 - 0.7 % SABIC Method
Density 1.2 g/cm? ISO 1183
Water Absorption, (23°C/sat) 0.35 % ISO 62
Moisture Absorption (23°C / 50% RH) 0.15 % ISO 62
Melt Volume Rate, MVR at 300°C/1.2 kg 26 cm?/10 min ISO 1133
ELECTRICAL Value Unit Standard
Volume Resistivity >1.E+15 Ohm-cm IEC 60093
Surface Resistivity, ROA >1.E+15 Ohm IEC 60093
Dielectric Strength, in oil, 3.2 mm 17 kV/mm IEC 60243-1
Relative Permittivity, 1 MHz 2.7 - IEC 60250
Dissipation Factor, 50/60 Hz 0.001 - IEC 60250
Dissipation Factor, 1 MHz 0.01 - IEC 60250
Relative Permittivity, 50/60 Hz 2.7 - IEC 60250
FLAME CHARACTERISTICS Value Unit Standard
Glow Wire Flammability Index 850°C, passes at 1 mm IEC 60695-2-12
Oxygen Index (LOI) 25 % ISO 4589

Parameter
Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 2 - 4 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 280 - 300 °C
Nozzle Temperature 270 - 290 °C
Front - Zone 3 Temperature 280 - 300 °C
Middle - Zone 2 Temperature 270 - 290 °C
Rear - Zone 1 Temperature 260 - 280 °C
Hopper Temperature 60 - 80 °C
Mold Temperature 80 - 100 °C
